Food Industry 304 Stainless Steel Conveyor Belt Customizable Dimension
Flat flex Stainless Steel conveyor belts are gear transmission belts with excellent ventilation advantages, even tension distribution, and fine workmanship. These belts feature flexible rotation, good stability, high temperature resistance, pressure resistance, corrosion resistance, and long service life.
Flat flex Stainless Steel conveyor belts utilize a single-layer structure, making them lighter and suitable for sprocket drive systems. With large open areas (70-85% opening), they are commonly used for cooling, frying, baking, drying, heating, decoration, powder wrapping, and packaging equipment for lighter weight products.
Flat-Flex stainless steel conveyor belts are available in a wide range of wire diameters and pitches. The specifications shown represent an extract from our full product range. Additional pitch and wire diameter variations are available - please consult our customer service team or technical sales engineers for specific requirements.
Product Specifications
| Item |
Flat flex wire mesh belt |
| Material |
304 stainless steel, 316 stainless steel, 201 stainless steel |
| Wire Diameter |
1.0mm - 3.0mm |
| Rod Pitch |
4.3mm - 20mm |
| Rod Width |
200mm - 3600mm |
Note: Pitch is generally customized according to client requirements, making this a non-standard conveyor belt.
- Primary material is 304 stainless steel wires from 1-3mm
- Simple structure results in more competitive pricing compared to other conveyor belt types
- Manufacturing process: wire bending - connection - edge treatment
- Standard pitches: 7.26mm and 12.7mm (custom sizes available)
- Compatible with: nylon sprockets and stainless steel sprockets
Product Applications
Flat flex Stainless Steel conveyor belts are primarily used in quick-frozen food processing, fried food production, sugar machinery, chocolate coating, and various bread and pastry baking conveyor lines. They are suitable for producing: small desserts, fish products, pizza, vegetables, bread, flour, cakes, meat, candy, potatoes, biscuits, chocolate, nuts, and fruit.
Product Features
The unique features of Flat-Flex stainless steel conveyor belts offer numerous benefits that increase productivity, help contain costs, and improve overall product quality:
- Largest proportion of open-mesh area available - up to 86%
- Easy to clean, clean-in-place design
- No-slip, positive drive system
- Very low belt mass
- Smallest diameter end rolls and drive rolls
- Positive driven for accurate tracking
- USDA Accepted
Flat-Flex stainless steel conveyor belts are available in various materials, with 302 stainless steel as standard. Other materials include: 316 stainless steel, various carbon steels, and high-temperature performance materials.
Flat-Flex's C-CureEdge Technology is available for most belts, eliminating the possibility of belt edge catching and tangling.
Additional Applications
- Freezing food industry
- Cooling processes
- Cooking applications
- Blanching vegetables
- Drying operations
- Metalworking and hardening
- Chemical industry for conveying rubber and plastic products
- Serving as screens, guards, and mesh panels
- Decoration purposes
- Heat treatment belts or pasteurizing belts
Company Profile
Anping Bingze Wire Mesh Products Co., Ltd. has specialized in stainless steel wire mesh production and research for 25 years. We are a comprehensive manufacturer integrating production, processing, distribution, and wholesale operations.
Our product portfolio includes: galvanized welded wire mesh, stainless steel welded wire mesh, PVC welded wire mesh, crimped wire mesh, galvanized woven wire mesh, stainless steel woven wire mesh, chain link fence, steel fence, welded wire mesh fence panels, PVC euro fence, 358 anti-climb fence, razor wire, and Hesco Barrier.
Since our establishment, we have focused on four core principles: High Quality, Quick Delivery, Competitive Pricing, and Thorough Service. Our commitment to product quality and credit standing has earned us favorable customer feedback.
We employ precise manufacturing machines and advanced techniques, combined with scientific management methods and quality control systems. Our products meet high standards and are exported worldwide to Southeast Asia, Middle East, America, Japan, and African countries.
Certifications
Frequently Asked Questions
Q: How long is your delivery time?
Generally 3-7 days for in-stock items, or 15-20 days for non-stock items depending on quantity.
Q: Do you provide samples?
Yes, we provide product samples for testing free of charge (freight collected by customer).
Q: How can I track my order completion?
Process: Deposit payment → Production start → Logistics information transfer → Shipment booking → ETD & ETA notification → Container loading → Balance payment → Document delivery
Q: How can I verify your company reliability?
We have been in business since 1987 with extensive exporting experience and hold multiple certifications.
